Weighing Scale
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Introduction:
The IS-E/F series weighing scale have stable weighing system, full range tare, counting,
unit conversion functions. Operator can set mini weighing by themselves, and choose the
suitable interface can connect with PC and other instruments.
Download
Features
*SUS Surface, fit for bigger goods；
*Plastic sprayed carbon steel base.
*Wide range, high precision sensor；
*LED display；
*Battery standard, ensure working Without power on
Technical Parameter:
|
Model |
IS-60E |
IS-100E |
IS-150E |
IS-200E |
IS-300E |
IS-500E |
IS-60F |
IS-100F |
IF-150F |
|
Capacity(kg) |
61 |
110 |
160 |
210 |
310 |
510 |
61 |
110 |
160 |
|
Resolution(G) |
10 |
50 |
1 |
||||||
|
Repeatability(G) |
±30 |
±150 |
±3 |
||||||
|
Linearity(G) |
±50 |
±250 |
±5 |
||||||
|
Pan Size |
400*500mm/450*600mm |
600*800mm |
400*500mm |
||||||
|
Resp. Time |
3sec |
||||||||
|
Sensitivity Drift |
±3ppm/℃ |
||||||||
|
Display |
LED |
||||||||
|
Sensor |
Load Cell |
||||||||
|
Operation Temp. |
5-25℃ |
||||||||
|
Power Supply |
AC220V, 50/60Hz(Standard); 110V, 60Hz（Optional） |
||||||||
|
Package Size(L*W*H) mm |
420*170*850 |
975*710*190; 320*210*145 |
420*170*850 |
||||||
|
Gross Weight(kg) |
14 |
45 |
14 |
||||||
